Main parameters | Parameter range |
Model | THT96G (gradient type) | THT96 (standard type) | THT48 (standard type) |
Temperature rise and fall technology | Semiconductor refrigeration |
LCD | 7-inch true color screen, curve graph display program |
U disk function | Unlimited download of programs via U disk |
Communication Interface | USB2.0*2 RS232 |
Support mouse | Use multi-user names; |
Computer connection | Password protection Wireless connection, one computer can connect 100 PCR instrument at the same time; The cable connection |
Support mouse | Have |
Language | Support Chinese and English |
Sample stage capacity | 0.2ml*96 hole | 0.2ml*48 hole |
Sample stage temperature range | 0℃-100℃ |
Maximum heating rate | 5℃/Second |
Maximum cooling rate | 5℃/Second |
Temperature uniformity of sample stage | ≤±0.2℃ |
Temperature accuracy of sample stage | ≤±0.2℃ |
Temperature display resolution | 0.1℃ |
Temperature control method | Analog tube + sample stage |
Variable temperature speed adjustable | Have |
Gradient temperature accuracy | ≤±0.2℃ | None |
Gradient temperature uniformity | ≤±0.2℃ | None |
Gradient range | 30℃-100℃ | None |
Temperature range | 0-30℃ | None |
Number of program storage | The instrument can store 120 programs, and can download unlimited programs via U disk |
Maximum number of steps | 40, can do multiple nested loops |
Maximum number of cycles | 100 standard loops (up to 60,000 nested loops) |
Time increase/decrease | 1-120 seconds, can do Long PCR experiment |
Temperature increase/decrease | 0.1-10.0℃, can do Touchdown PCR experiment |
Auto pause | Have |
Power failure protection | Have |
heat preservation | Infinite holding time |
Run time display | Have |
Real Time Clock | Have |
Hot lid temperature | 30℃-110℃ adjustable |
Heat cover height | Stepless free adjustment, adapt to different PCR tubes |
Hot lid repressurization technology | Two levels of adjustment, no matter how many sample tubes are running during the experiment, the pressure of the sample tube can be kept constant |
The hot lid closes automatically | When the set temperature of the sample stage is lower than 30℃ or the program ends, it will automatically shut down |
Input power, power | Universal power supply (220VAC/47-65Hz), 200W-600W |
Size, net weight | 303mm*243mm*273mm,9Kg |
notepad | Have |
Tm value calculated | Have |
More sample table capacity | 0.2ml*96 hole+0.5ml*77 hole, 0.2ml*48 hole+0.5ml*48 hole 0.2ml*108 hole +0.5ml*88 hole,0.2ml*384 hole,0.2*48 hole,0.2ml*32 hole。Can add, |
